PowerCube Series

PowerCube Series

  • User Friendly LED Indicator
  • Wall-Mounted Design
  • Microprocessor Control Guarantees High Reliability
  • 4 x 13Amp British Output Socket c/w Safety Window + 2 x IEC Output Socket
  • Built-in Boost & Buck AVR
  • High Quality SLA Maintenance Free Battery
  • Hot-Swappable Battery Design
  • Built-in EMI/RFI Noise Filter
  • Green Power Function for Energy Saving
  • Lightning, Spike & Surge Protection
  • Modem/Fax/Network Line Protection (RJ11/RJ45)
  • Comes with RS 232 Port, USB Port & Power Management Software



Share Item :

Technical Specifications

MODEL PowerCube 800G2
CAPACITY (VA/WATTS) 800VA
INPUT
INPUT VOLTAGE 220V/230V/240V
VOLTAGE RANGE 162 - 290VAC
INPUT FREQUENCY 45-65Hz (Auto-sensing)
OUTPUT
OUTPUT VOLTAGE 220V/230V/240V
VOLTAGE REGULATION (Battery Mode) +/-10%
OUTPUT FREQUENCY 50Hz or 60Hz
FREQUENCY REGULATION (Battery Mode) +/-1 Hz
WAVEFORM Simulated Sinewave
TRANSFER TIME (Typical) 2ms - 6ms
OUTPUT SOCKET 4 x 13Amp British Socket c/w Safety Window + 2 x IEC Output Socket
BATTERY
SEALED LEAD ACID MAINTENANCE FREE BATTERY 12V 7Ah x 1pc
HOT-SWAPPABLE BATTERY (USER REPLACEABLE DESIGN) Yes ( Able to replace battery without turning off UPS )
BACK UP TIME (Depending on Load) 20 - 30 Minutes
RECHARGE TIME 3 Hours to 90% After Complete Discharge
STATUS INDICATOR
LED INDICATOR AC Mode - Green LED Lighting
Battery Mode - Yellow LED Flashing
UPS Fault - Red LED Lighting
AUDIBLE ALARM Backup Mode - Beeping every 10 seconds
Low Battery - Beeping every second
Battery Replacement - Sounding every 2 seconds
Overload - Beeping every 0.5 seconds
UPS Fault - Continuously Beeping
COMMUNICATION
POWER MANAGEMENT SOFTWARE -Automatically Shutdown, Saves Application Data Before Exit
-Power Flow Display for Monitoring UPS Status
-Schedules System Shutdown/Restart
-Warning Notification Via Email/Pager/Broadcast
-Remote Monitor/Control via LAN
- Safety Shutdown Multi System
INTERFACE RS232 & USB Port
SURGE PROTECTION & FILTERING
FULL PROTECTION Discharge, Overcharge and Overload Protection
LIGHTNING, SURGE PROTECTION Yes
OVERLOAD PROTECTION Fuse, Current Limited & Cut-off (Re-settable Circuit Breaker)
PHONE/FAX/MODEM/NETWORK PROTECTION RJ45 ( 1 in 1 out)
PHYSICAL
OPERATING ENVIRONMENT 0-40℃, 0-90% Relative Humidity (Non-Condensing)
NOISE LEVEL Less than 40dB
DIMENSION (D x W x H)mm 292 x 199 x91
WEIGHT (KG) 5.8
WARRANTY
UPS WARRANTY 3 Years Full Warranty include Parts & Labour
2 Years Warranty for Battery
